Today it goes into the sleep laboratory. We put the ESP32/ESP8266 to rest, which helps save electricity in battery operation. In addition, the RTC module of the Micropython kernel and the DS1302 also offer the opportunity to store data that survive a restart. Usually, all variables and objects are gone when the controller restarts. How they can be preserved and which sleep modes and revival options ESP8266 and ESP32 offer, you will find out in

Micropython on the ESP32 and ESP8266

today

Sleeping Beauty sleep

We won't send our ESPs to hibernation for 100 years and we won't be kisses awake either. We prefer to leave that to the RTC. With the ESP32 we can also crawl some legs and if there is a level change, this can also lead to the controller waking up. In any case, he makes a restart and everything that was in the RAM has emigrated to nirvana. Everything, except for the data in the RTC RAM and the RTC itself. What do we need for the experiments?

Hardware

1

ESP32 Dev Kit C unpleasant or

ESP32 Dev Kit C V4 unplacerated or

ESP32 NODEMCU Module WiFi Development Board with CP2102 or

Nodemcu-ESP-32S kit

1

Nodemcu Lua Amica Module V2 ESP8266 ESP-12F WiFi or

D1 Mini Nodemcu with ESP8266-12F WLAN module or

Nodemcu Lua Lolin V3 Module ESP8266 ESP-12F WIFI

1

0.91 inch OLED I2C Display 128 x 32 pixels

1

Ky-004 button module

1

Breadboard Kit - 3x Jumper Wire M2M/F2M/F2F + 3 Set MB102 Breadboard Compatible with Arduino and Raspberry Pi - 1x Set

1

DS1302 Serial Real Time Clock RTC real-time clock Clock module

The software

For flashing and the programming of the ESP32:

Thonny or

µpycraft

Used firmware for the ESP8266:

V1.19.1 (2022-06-18).

Used firmware for the ESP32:

V1.19.1 (2022-06-18).

The micropython programs for the project:

ds1302.py Hardware driver for the DS1302

SSD1306.PY Hardware driver for the OLED display

oled.py API for the OLED display

DS1302 Set+Get.PY Program for the watch comparison NTP-RTC-DS1302

rtc set+get.py Program for the watch comparison NTP-RTC

wake_on_gpio.py Deep sleep and awakening by changing the level

deep sleep_demo.py Deep sleep and awakening by timer

Sleep types.py Possibilities for saving electricity

Sleep+Wachen.Py Test program for electricity savings on ESP8266 and ESP32

Micropython - Language - Modules and Programs

To install Thonny you will find one here Detailed instructions (English version). There is also a description of how the Micropython firmware (As of 18.06.2022) on the ESP chip burned becomes.

Micropython is an interpreter language. The main difference to the Arduino IDE, where you always flash entire programs, is that you only have to flash the Micropython firmware once on the ESP32 so that the controller understands Micropython instructions. You can use Thonny, µpycraft, or ESPTOOL.PY. For Thonny I have the process here described.

As soon as the firmware has flashed, you can easily talk to your controller in a dialogue, test individual commands and see the answer immediately without having to compile and transmit an entire program beforehand. That is exactly what bothers me about the Arduino IDE. You simply save an enormous time if you can check simple tests of the syntax and hardware to try out and refine functions and entire program parts via the command line before knitting a program from it. For this purpose, I always like to create small test programs. As a kind of macro, they summarize recurring commands. Whole applications then develop from such program fragments.

Autostart

If the program is to start autonomously by switching on the controller, copy the program text into a newly created blank tile. Save this file under boot.py in WorkSpace and upload it to the ESP chip. The program starts automatically the next time the reset or switching is on.

Test programs

Programs from the current editor window in the Thonny-IDE are started manually via the F5 button. This can be done faster than the mouse click on the start button, or via the menu run. Only the modules used in the program must be in the flash of the ESP32.

In between, Arduino id again?

Should you later use the controller together with the Arduino IDE, just flash the program in the usual way. However, the ESP32/ESP8266 then forgot that it has ever spoken Micropython. Conversely, any espressif chip that contains a compiled program from the Arduino IDE or AT-Firmware or Lua or ... can be easily provided with the Micropython firmware. The process is always here described.

The circuits

Figure 1: ESP8266 - circuit

Image 1: ESP8266 - circuit

So that the ESP8266 can wake up, you have to connect the PIN GPIO16 = D0 to the RST connection. With the button module, I give the ESP8266 a flash key because the poor guy itself has no one on board.

An ESP32 doesn't need all of this. Nevertheless, he also gets a button from me so that he doesn't cry and above all so that I can tease it up.

Figure 2: ESP32 - circuit

Image 2: ESP32 - circuit

The controller goes to sleep

Well then good night!

This can be said if you have not kept it open to wake up the guy again, for example, to upload changes to the program. Because the ESP32/ESP8266 must of course be wide awake. We are looking at which sleep modes are available and, above all, what revival methods are available.

First of all, it is striking that the kernel for ESP8266 and ESP32 have different features. Thonny's object inspector explains. You can use the menu View - Object Inspector start.

Figure 3: The ESP8266 Machine module

Image 3: The ESP8266 Machine module

Figure 4: The ESP32 Machine module

Image 4: The ESP32 Machine module

ESP8266

Deep sleep and reset

Let's slowly approach the matter. In interactive mode, i.e. via Repl, I put some commands off. I import some classes and functions, declare the tufle rtctag, and instantiate the object RTC.

>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> rtctag=(2022,11,27,8,10,20,0,0)
>>> RTC=RTC()
>>> rtctag
(2022, 11, 27, 8, 10, 20, 0, 0)

The function reset_cause() As a reason for a reset, provides a number code according to the following Table 1.

ESP8266



Pwron_reset

0

after turning on

Wdt_reset

1

According to the response of the Cerberus (= Watchdog aka Wachhund)

Soft_reset

4

After calling the Machine.Reset function ()

Deepsleep_reset

5

After awakening from deep sleep

Hard_reset

6

After pressing the RST key

Table 1: Reset codes

Immediately after switching on, we get a 0 at the ESP8266. After a soft reset, a 4.

>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> reset()
.
>>> reset_cause()
4
>>> rtctag
Traceback (custody recent call load):
 File "", line 1, in <modules>
Name: Surname 'rtctag' isn't defined

With a hard reset like a soft reset, the data from the RAM disappeared and migrated to nirvana. So I had to import again.

Now plug a jumper wire from D0 = GPIO16 to the PIN RST on the Breadboard, as shown in Figure 1 above.

Now we send the ESP8266 to sleep for 5 seconds. If no time is handed over, the controller sleeps to St. Nimmerleinstag and can only be teased awake through the RST button.

>>> Deepsleep(5000)
…….
Micropython V1.19.1 on 2022-06-18; ESP modules wither ESP8266
Type "Help ()" for more information.

>>> reset_cause()
Traceback (custody recent call load):
 File "", line 1, in <modules>
Name: Surname 'reset_cause' isn't defined

The controller also forgot after awakening from deep sleep what we had imported on tools. So again from the front. This time we still put the RTC and convince ourselves whether it is ticking.

>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> rtctag=(2022,11,27,0,8,10,20,0)
>>> RTC=RTC()
>>> RTC.DateTime(rtctag)
>>> RTC.DateTime()
(2022, 11, 27, 6, 8, 10, 31, 367)

>>> Deepsleep()
…….
Micropython V1.19.1 on 2022-06-18; ESP modules wither ESP8266
Type "Help ()" for more information.

>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> reset_cause()
5
>>> RTC=RTC()
>>> RTC.DateTime()
(2022, 11, 27, 6, 8, 12, 15, 959)

Aha! After awakening from deep sleep, the controller can remember the time, he even continued the count of seconds. The situation is similar to a bytes object that can be written in the RTC memory. The ESP8266 can be around 500 bytes, and the ESP32 2000.

>>> RTC.memory(B "12345 this is a test!")
>>> RTC.memory()
B'12345 that's a test! '

>>> Deepsleep()
…….
Micropython V1.19.1 on 2022-06-18; ESP modules wither ESP8266
Type "Help ()" for more information.

>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> RTC=RTC()
>>> RTC.memory()
B'12345 that's a test! '

This also works after a soft reset.

>>> reset()
…….
Micropython V1.19.1 on 2022-06-18; ESP modules wither ESP8266
Type "Help ()" for more information.

>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> RTC=RTC()
>>> RTC.memory()
B'12345 that's a test! '
>>> reset_cause()
4

And even after a hard reset (RST key), the data is still there.

And even after a Hard-Reset (RST-button) are the Data still there.
>>> From machine import RTC, Deepsleep, reset_cause, reset
>>> RTC=RTC()
>>> RTC.memory()
B'12345 that's a test! '
>>> reset_cause()
6
>>> RTC.DateTime()
(2022, 11, 27, 6, 8, 20, 9, 603)

However, the RTC module is also deleted after a power failure, there is no buffer battery. So if you want to secure data in the switch-off state, then there are only two ways: either in a file in the flash memory of the controller, in the buffered RAM of a DS1302, or in a corresponding component.

Easy sleep

After the easy sleep, the ESP8266 can still remember the previously carried out value assignments of variables, of course also of the content of the RTC RAM storage.

>>> From machine import RTC, reset_cause, Lightsleep
>>> RTC=RTC()
>>> sleep=5000
>>> RTC.memory(B "1234 this is a test")
>>> Lightsleep(3000)
>>> RTC.memory()
B'1234 This is a test '
>>> sleep
5000

If we translate these commands into a program, we will find that this is continued in the line, which on the call of Lightsleep() follows.

While a current of 78 mA now flows in normal mode, it is reduced to values ​​between 25 mA and 35 mA in Lightsleep mode. The current strength goes back to 3.3 mA in Deepsleep mode.

The RTC area is therefore always protected against data loss, provided the ESP8266 is supplied with sufficient voltage. The objects in normal RAM are only preserved in Lightsleep mode. When the board is switched off, the data is only preserved in an external battery-buffered RAM, as in the DS1302, or in a file in the flash of the controller block.

If the program is to be continued at the point after the sleep command, only the Lightsleep mode is suitable. A cold start is practically in Deep-sleep mode, in which the main program is started from the start.

With Sleep+Wachen.Py I made a program that can be used on the ESP8266, but it also runs on the ESP32 and helps to examine the various features of both systems.

# Sleep+Wachen.PY
#
From machine import reset_cause,\
    Deepsleep, Lightsleep, \
    sleep, Softi2c, Pin code
import sys
From OLED import OLED

port=sys.platform
lifetime=5000
sleep=5000
button=Pin code(0,Pin code.IN,Pin code.Pull_up)
wakepin=Pin code(14)

IF port == "ESP8266":
   I2C=Softi2c(scl=Pin code(5),sda=Pin code(4))
   ground={
       0:"Poweron Reset",
       1:"Watchdog Reset",
       2:"???",
       4:"Soft Reset",
       5:"Deepsleep Reset",
       6:"Hard Reset",
      }
   RC=reset_cause()
elif port == "ESP32":
   I2C=Softi2c(scl=Pin code(22),sda=Pin code(21))
   From machine import wake_reason
   import ESP32
   ESP32.wake_on_ext0(wakepin,ESP32.Wakeup_all_low)
   ground={
       1:"Poweron Reset",
       2:"Ext0 Wake",
       3:"Ext1 Wake",
       4:"Deepsleep Reset",
       5:"Touch Wake",
       6:"Ulp Wake",
      }
   RC=wake_reason()
Else:
   raise Runtime("Unknown Port")

print("Restarted by:",RC,ground[RC])
D=OLED(I2C,Heightw=64) # 128x32 pixel display
D.clearall()
D.writer("Restart through",0,0)
D.writer("{}".format(RC),0,1)
D.writer(ground[RC],0,2)
sleep(3000)

print(port, "walks into",lifetime,"MS sleep")
D.clearall()
D.writer("I'M AWAKE",0,0)
D.writer("for".format(RC),0,1)
D.writer("{} ms".format(lifetime),0,2)
sleep(lifetime)
IF button.value() == 0:
   D.clearall()
   D.writer("PROGRAM",0,0)
   D.writer("COMPLETED",0,1)
   sys.exit()

print(port, "Schlaeft now",sleep,"MS")
D.clearall()
D.writer("I AM SLEEPING",0,0)
D.writer("Now for".format(RC),0,1)
D.writer("{} ms".format(sleep),0,2)

# Lightsleep (Sleeptime)
Deepsleep(sleep)

IF port == "ESP8266":
   RC=reset_cause()
Else:
   RC=wake_reason()
print(port, "I woke up",sleep,"MS")
D.clearall()
D.writer("WOKE UP",0,0)
D.writer("THROUGH {}".format(RC),0,1)
D.writer(ground[RC],0,2)

In order for electricity measurements to be carried out, the ESP8266 board must be separated from the USB bus and supplied from its own source of voltage. To get feedback, I used an OLED display.

After importing some classes and functions, I declare a few variables and objects. The backslash allows me to extend the list over several lines.

From machine import reset_cause,\
    Deepsleep, Lightsleep, \
    sleep, Softi2c, Pin code
import sys
From OLED import OLED

port=sys.platform

The string constant sys.platform says which controller I have.

lifetime=5000
sleep=5000

Two variables for the wax and sleep phase

button=Pin code(0,Pin code.IN,Pin code.Pull_up)

With the flash button on GPIO0, I can cancel the program so that I don't get into the sleep phase if I want to upload program changes. With the combination Ctrl+C, It's not always that easy.

wakepin=Pin code(14)

For the ESP32 I define a PIN object with which I want to wake up the controller. This feature does not exist with the ESP8266. You could only use the RST key.

Depending on the port, I then carry out further actions.

IF port == "ESP8266":
   I2C=Softi2c(scl=Pin code(5),sda=Pin code(4))
   ground={
       0:"Poweron Reset",
       1:"Watchdog Reset",
       2:"???",
       4:"Soft Reset",
       5:"Deepsleep Reset",
       6:"Hard Reset",
      }
   RC=reset_cause()

There is not much to do with the ESP8266. The right i2C pins must be defined and the dictionary for the plain text of the Reset Ground must be declared. The function reset_cause () reveals the reason for the last reset. In Table 1 you will find an overview.

elif port == "ESP32":
   I2C=Softi2c(scl=Pin code(22),sda=Pin code(21))
   From machine import wake_reason
   import ESP32
   ESP32.wake_on_ext0(wakepin,ESP32.Wakeup_all_low)
   ground={
       1:"Poweron Reset",
       2:"Ext0 Wake",
       3:"Ext1 Wake",
       4:"Deepsleep Reset",
       5:"Touch Wake",
       6:"Ulp Wake",
      }
   RC=wake_reason()
Else:
   raise Runtime("Unknown Port")

For the ESP32 DITO, also two more imports, as well as the call of wake_on_ext0 (), to end the sleep mode by pressing a button on GPIO14. As you can see, there is a different assignment of the wake or reset events than the ESP8266. For the query of the reason, the function is the function of the ESP32 wake_reason() responsible. If it is not an ESP32 or ESP8266 board (PY board etc.), the program throws an exception.

print("Restarted by:",RC,ground[RC])
D=OLED(I2C,Heightw=64) # 128x32 pixel display
D.clearall()
D.writer("Restart through",0,0)
D.writer("{}".format(RC),0,1)
D.writer(ground[RC],0,2)
sleep(3000)

The following block provides information about the restart and its background in the terminal window and on the OLED display. The function is remarkable sleep(). Because she doesn't live in the module time, but in a machine. The delay is also not specified in seconds but in milliseconds. To do this, also compare Images 3 and 4.

print(port, "walks into",lifetime,"MS sleep")
D.clearall()
D.writer("I'M AWAKE",0,0)
D.writer("for".format(RC),0,1)
D.writer("{} ms".format(lifetime),0,2)
sleep(lifetime)
IF button.value() == 0:
   D.clearall()
   D.writer("PROGRAM",0,0)
   D.writer("COMPLETED",0,1)
   sys.exit()

Then the controller tells me that he is now still awake for 5 seconds. At the end of the waking phase, I have the opportunity to stop the program clean when I press and hold the flash button during this time. With an ESP8266 Node McU or one Amica If this is on the board, the ESP8266 D1 Mini (Pro) I have to sponsor an extra key module.

print(port, "Schlaeft now",sleep,"MS")
D.clearall()
D.writer("I AM SLEEPING",0,0)
D.writer("Now for".format(RC),0,1)
D.writer("{} ms".format(sleep),0,2)

# Lightsleep (Sleeptime)
Deepsleep(sleep)

Shortly before the controller goes to sleep, he informs me about it. Depending on which of the two lowest lines, the ESP8266/ESP32 now falls into a deep sleep in light or, as here.

IF port == "ESP8266":
   RC=reset_cause()
Else:
   RC=wake_reason()
print(port, "I woke up",sleep,"MS")
D.clearall()
D.writer("WOKE UP",0,0)
D.writer("THROUGH {}".format(RC),0,1)
D.writer(ground[RC],0,2)

If it was a deep sleep, I never see this last edition, because in this case, the program starts again. If it was Lightsleep, the program continues with the IF construct.

ESP32

The module machine The ESP32 also knows the two sleep modes: Lightsleep and Deepsleep. With the ESP32, I could not find any great differences in electricity consumption. When awake, the circuit of Image 2, if no program runs, pulls 38mA. During the command sleep Runs, flow 13MA, in deep sleep 12mA. The OLED display has a share of 3MA. When restarting, the current increases briefly to over 50 mA. But there is no significant difference in the current between Lightsleep and Deepsleep. If program commands are carried out during the waiting phases, the current strength is also almost 50 mA.

You can awaken the ESP32 in several types, timely-controlled by pressing a button that must be connected to one of the RTC GPIOs, or via a touchpad on one of the corresponding touch GPIOS. I present a sample program. The basis is the program Sleep+Wachen.Py, which experiences changes in corresponding places. The functions to be called are in the module ESP32 At Home, which is logically not available to the ESP8266.

The timer-controlled awakening happens with the ESP32 as well as the ESP8266 and therefore does not require any further explanation. On the other hand, it is new to awakening via one or more buttons or via a touchpad. With the function wake_reason() from the module machine, which only exists in the ESP32, the reason for awakening can be queried.

ESP32



Pwron_reset

1

after turning on

Ext0_wake

2

After pressing a button

Ext1_wake

3

After pressing one of several buttons

Deepsleep_reset

4

After awakening from deep sleep

TouchPad_wake /

Soft_reset

5

After touching a touchpad

After calling the Machine.Reset function ()

Ulp_wake

6

Ultra low power processor

Table 2

Wake_on_ext0

With this function from the module ESP32, I open up the possibility of ending the sleep phase, no matter which one, via touch pressure.

wakepin=Pin code(14)
import ESP32
ESP32.wake_on_ext0(wakepin,ESP32.Wakeup_all_low)

With wakepin I hand over a pin object. One of the RTC GPIOs must be selected as a connection because only these are still active during the rest period. Nevertheless, the normal GPIO number is specified when the pin object is instantiated. Table 3 shows which connections can be considered.

Rtc_gpio0

 GPIO36

Rtc_gpio3

 GPIO39

Rtc_gpio9

 GPIO32

Rtc_gpio8

 GPIO33

Rtc_gpio6

 GPIO25

Rtc_gpio7

 GPIO26

Rtc_gpio17

 GPIO27

Rtc_gpio16

 GPIO14

Rtc_gpio15

 Gpio12

Rtc_gpio14

 GPIO13

Rtc_gpio11

 GPIO0

Rtc_gpio13

 GPIO15

Rtc_gpio12

 Gpio2

Rtc_gpio10

 GPIO4

Table 3

In the program Sleep+Wachen.Py If waking up is already installed by a button. The constant ESP32.Wakeup_all_low Has the value False (See Image 5) and ensures that the ESP32 wakes up when a low level is available on GPIO14. This corresponds to the circuit in Image 2. Alternatively, with Wakup_any_high The ESP32 wakes up when the level goes to 3.3V.

Figure 5: Attributes of the ESP32 module

Image 5: Attributes of the ESP32 module

wake_on_ext1

With wake_on_etx1 (), several keys can wake up the ESP32. The PIN objects are then as a tupel or as list handover. The corresponding lines could look like this.

wakepin = Pin code(14)
button = Pin code(0,Pin code.IN,Pin code.Pull_up)
Keys = (wakepin, button)
import ESP32
ESP32.wake_on_ext1(tasty,ESP32.Wakeup_all_low)

Now the ESP32 can also be woken up via the flash key.

wake_on_touch

Also about one touchpoint can wake up the ESP32. It is possible to connect several touchpads. However, it cannot be worked on buttons at the same time, the interpreter reports a mistake.

Traceback (custody recent call load):
 File "", line 37, in <modules>
Value: NO resources

The elif-Part could now look like this. The wake_on_ext0-Iity is commented on.

elif port == "ESP32":
   I2C=Softi2c(scl=Pin code(22),sda=Pin code(21))
   From machine import wake_reason, Touchpad
   import ESP32
   wake1 = Pin code(15, Fashion = Pin code.IN)
   wake2= Pin code(2, Fashion = Pin code.IN)
   Touch1 = Touchpad(wake1)
   Touch2= Touchpad(wake2)
   Touch1.config(300)
   Touch2.config(300)
   ESP32.wake_on_touch(True)
   #ESP32.Wake_On_EXT0 (WAKEPIN, ESP32.Wakeup_all_low)
   ground={
       1:"Poweron Reset",
       2:"Ext0 Wake",
       3:"Ext1 Wake",
       4:"Deepsleep Reset",
       5:"Touch Wake",
       6:"Ulp Wake",
      }
   RC=wake_reason()

I have connected two pieces of boards to the Pins GPIO15 and GPIO2. The two touchpad objects generated are configured so that the TouchX.Read() read value without touch (e.g. 419) well above that of the method config() handed over and the value determined with touch (e.g. 65) significantly below.

If the program is started a second time and the ESP32 woken up with a touch, we get the reason for the previous awakening correctly.

Restart from: 5 Touch Wake
This is the Constructor of Oled Class
Size: 128x32
ESP32 goes in 5000 MS sleep
ESP32 Schlaeft now 5000 MS
Lightsleep(sleep)
# Deepsleep (Sleeptime)
If Lightsleep is activated instead of deep sleep, the program part is executed after the call, regardless of whether the ESP32 is covered by the timer or by touch or buttons. Then the program ends. If this part is to be run through several times, you would have to pack it in a while loop, this:
# Sleep+Wachen.PY
#
From machine import reset_cause,\
    Deepsleep, Lightsleep, \
    sleep, Softi2c, Pin code
import sys
From OLED import OLED

port=sys.platform
lifetime=5000
sleep=5000
button=Pin code(0,Pin code.IN,Pin code.Pull_up)
wakepin=Pin code(14)

IF port == "ESP8266":
   I2C=Softi2c(scl=Pin code(5),sda=Pin code(4))
   ground={
       0:"Poweron Reset",
       1:"Watchdog Reset",
       2:"???",
       4:"Soft Reset",
       5:"Deepsleep Reset",
       6:"Hard Reset",
      }
   RC=reset_cause()
elif port == "ESP32":
   I2C=Softi2c(scl=Pin code(22),sda=Pin code(21))
   From machine import wake_reason, Touchpad
   import ESP32
   wake1 = Pin code(15, Fashion = Pin code.IN)
   wake2= Pin code(2, Fashion = Pin code.IN)
   Touch1 = Touchpad(wake1)
   Touch2= Touchpad(wake2)
   Touch1.config(300)
   Touch2.config(300)
   ESP32.wake_on_touch(True)
   #ESP32.Wake_On_EXT0 (WAKEPIN, ESP32.Wakeup_all_low)
   ground={
       1:"Poweron Reset",
       2:"Ext0 Wake",
       3:"Ext1 Wake",
       4:"Deepsleep Reset",
       5:"Touch Wake",
       6:"Ulp Wake",
      }
   RC=wake_reason()
Else:
   raise Runtime("Unknown Port")
while 1:
   print("Restarted by:",RC,ground[RC])
   D=OLED(I2C,Heightw=32) # 128x32 pixel display
   D.clearall()
   D.writer("Restart through",0,0)
   D.writer("{}".format(RC),0,1)
   D.writer(ground[RC],0,2)
   sleep(3000)

   print(port, "walks into",lifetime,"MS sleep")
   D.clearall()
   D.writer("I'M AWAKE",0,0)
   D.writer("for".format(RC),0,1)
   D.writer("{} ms".format(lifetime),0,2)
   sleep(lifetime)
   IF button.value() == 0:
       D.clearall()
       D.writer("PROGRAM",0,0)
       D.writer("COMPLETED",0,1)
       sys.exit()

   print(port, "Schlaeft now",sleep,"MS")
   D.clearall()
   D.writer("I AM SLEEPING",0,0)
   D.writer("Now for".format(RC),0,1)
   D.writer("{} ms".format(sleep),0,2)

   Lightsleep(sleep)
   # Deepsleep (Sleeptime)

   IF port == "ESP8266":
       RC=reset_cause()
   Else:
       RC=wake_reason()
   print(port, "I woke up",sleep,"MS")
   D.clearall()
   D.writer("WOKE UP",0,0)
   D.writer("THROUGH {}".format(RC),0,1)
   D.writer(ground[RC],0,2)
   sleep(3000)

Figure 6: ESP8266-Nodemcu with DS1302-RTC

Image 6: ESP8266-Nodemcu with DS1302-RTC

With all the new findings, you are now able to develop more battery-saving circuits and preserve data beyond the sleep phases. However, it turned out that the effect on the ESP8266 is clearer than with his big brother. I could not determine the electricity strengths of a few µA in the deep sleep phase in any of the boards examined. Such information is probably only related to the chip and not to the entire board. However, the latter is crucial.

Esp-32Esp-8266Projekte für anfängerSmart homeStromversorgung

7 commentaires

Werner

Werner

bei den Dateien wake_on_gpio.py und schlafarten.py kommt die Fehlermeldung:
“Not Found

The requested URL was not found on this server."

MisterD

MisterD

Spannend wäre den testaufbau gleich noch für mehrere verschiedene Boards zu nutzen,vor allem würden mich der pico und pico w interessieren.

Thomas

Thomas

Alter Kaffee. Solche Untersuchungen, allerdings in C++, gibt es schon seit Jahren. Einen nackten ESP (ohne USB, ohne ASM1117 und ohne LED) kann man auf ein paar µA im Schlaf trimmen. Wer wirklich mit Akku oder Batterie sinnvoll im Langzeitmodus expeirmentieren will, sollte daher keinen NodeMCU, Wemos oder ähnliches verwenden, sondern immer auf den nackten ESP zurückgreifen und ein bisschen löten. Es sei denn, er überlässt die Tiefschlafsteuerung einem Attiny oder einem Echtzeit-RTC, um den EN-PIN mittels geeigneter Schaltung auf VCC zu setzen bzw. zu trennen. Man muss dan naber auch damit leben, dass der ESP einen Neustart macht und nur noch weiß, was er im RTC-Memory oder im Flash als Datei gespeichert hat.

Reiner Knapp

Reiner Knapp

Nur so als Hinweis zum Stromverbrauch mein Vortrag auf der Piandmore: https://piandmore.de/de/conference/pam12/call/public-media/2289

Man sollte sich nicht mit 12mA Stromverbrauch im standby zufrieden geben!

Harald

Harald

Das Unternehmen ist recht sinnlos. Zum Stromsparen muß man die reinen ESPs verwenden. Durch die Breakout-Boards wird extrem viel Strom verbaraucht. Deshalb ist auch zweischen light- und deep-sleep nur ein geringer Unterschied meßbar.

Veit

Veit

Hallo
Tolles Projekt. Leider nur in Micro Python. Ich bin fast 70 Jahre und habe mich in die Arduino IDE eingearbeitet. Mühselig und Langsamm !!
Eine neue Sprache muss und will ich nicht noch anfangen.
Viele Grüße an das tolle Team und weiter so.

Herbert Dietl

Herbert Dietl

Hallo, folgende py codes lassen sich nicht downloaden:
wake_on_gpio.py
schlafarten.py

Laisser un commentaire

Tous les commentaires sont modérés avant d'être publiés

Articles de blog recommandés

  1. ESP32 jetzt über den Boardverwalter installieren - AZ-Delivery
  2. Internet-Radio mit dem ESP32 - UPDATE - AZ-Delivery
  3. Arduino IDE - Programmieren für Einsteiger - Teil 1 - AZ-Delivery
  4. ESP32 - das Multitalent - AZ-Delivery
